Cast Steel Globe Valve


Cast Steel Globe Valve

Get Best Quote

We manufacture all types of Globe Valves under our brand FALCON. They are available in On-Off Disc, Control Disc and Parabolic Disc types. FALCONGlobe Valves are manufactured in almost all material like C.I, SG IRON, WCB, LCB, WC-1, WC-6, WC-9, CF-8, CF-8M, CF-3, CF-3M, CN-7M, HV-9, CD4-Cu., Hastelloy etc. Product range commences from 50 NB through 300 NB in size and BS/ANSI 150# through 2500# and PN-10 through PN-250 in pressure rating. STELLITE trim are provided for all Valves of 600# and higher ratings as a manufacturing standard of FALCON Valves and in lower rating on special requirement.



FALCON Globe Valves are meticulously designed to ensure 100% smooth flow area to reduce pressure drop across the Valve. Specially designed Seat and Packing material are provided for superheated steam and high temperature oils and fluids to ensure trouble free service and longer life. A properly machined and lapped backseat facilitates replacement of Gland Packing when Valve is in full stream.



Even though, the normal production restricts up to 400 NB, tailor-made/custom-made in larger sizes, higher pressure ratings, special material of construction are also entertained.



FALCON Globe Valves are inspected and certified by our own Q.C. Department. In the meantime, Clients' or any Third Party Inspection by an internationally reputed agency is also entertained as per requirement of Clients.


Yes! I am interested

Submit Your Requirement


Technical Specification

Size Range 50 NB
through
300 NB
Pressure Rating ANSI - 150#, 300#,
400#, 600#, 900#,
1500#, 2500#
Type OS & Y, Bolted/
Pressure Seal
Bonnet
End Connection Flanged/ Butt Weld
Operation Hand Wheel/ Manual
Gear/ Electric Motor
Actuator
Port Opening Full
Seat Integral/ Renewable/
Weld deposited
Disc Swivel - Flat/ Taper/
Control/ Parabolic
Gasket & Packing PTFE/ Graphite/ Asbestos/
Spiral wound/ Ring joint
MOC Refer Material Chart
Design Code BS 1873, DIN - 2401
Testing BS 5146
Inspection 3rd Party/ Client/
Manufacturer
